Create and share a reliable ADSL2+ broadband Internet connection with no fuss. The ADSL2+ Wireless N150 Modem Router simultaneously connects multiple devices wirelessly and includes 4 Ethernet ports for wired device connectivity. The WPS push button makes getting started a breeze, and settings are easily changed via the web interface. And with a host of advanced security features your network will remain protected at all times.
ADSL2+. Enhanced bandwidth.
Connect to an ADSL2+ service for improved performance and high-speed data transfer rates with the capacity to support all of your online activities. Where an ADSL2+ service is unavailable the Router will connect to ADSL or ADSL2 networks.
Complete WiFi.
With a built-in wireless access point that delivers wireless speeds of up to 150Mbps, multiple users can connect any smart phone, laptop, tablet computer, gaming console or wireless media player to the Internet in preferred locations without the need for wires.
Efficient Ethernet.
Ideal for connecting IPTVs, PCs and other high-bandwidth devices, the ADSL2+ Wireless N150 Modem Router lets you make multiple wired connections to the Internet using the built-in 4 port Ethernet switch
Technical Specifications
ADSL COMPLIANCE
Full-rate ANSI T1.413 Issue 2
ITU G.992.1 (G.dmt) Annex A or B
Splitterless ITU G.992.2 (G.lite) specification
ITU G.994.1 (G.hs)
ITU G.992.3 (G.dmt.bis / ADSL2)
ITU G.992.5 (ADSL2+) Annex M
Supports splitterless ADSL implementation
Supports Dying Gasp
ATM SUBSYSTEM
PPP over ATM (RFC 2364)
Bridged IP over ATM (RFC 1483)
PPP over Ethernet (RFC 2516)
Multiprotocol Encapsulation over AAL5 (RFC 2684)
Supports up to 8 Virtual Channel Connections (VCCs)
Supports VPN pass-through
Supports UBR, CBR, and VBR service classes
ATM Forum UNI 3.1 / 4.0 PVC
Support OAM F4 / F5 look-back, AIS and RDI OAM cells
FEATURES
IP Alias
User Datagram Protocol (UDP)
Transmission Control Protocol (TCP)
Internet Control Message Protocol (ICMP)
Internet Group Management Protocol (IGMP)
PPP over PAP (RFC1334)
PPP over CHAP (RFC1994)
MIB II support (RFC1213)
Transparent bridging as specified in IEEE 802.1D
NAT (Network Address Translation)
Dynamic Host Configuration Protocol (DHCP)
Dynamic DNS support
Routing Information Protocol (RIP) v1 and v2
WIRELESS
Compliant 802.11n
1T1R antenna configuration
Supports 64 / 128 bits WEP and WPA
150 Mbps maximum data rate
Supports 802.11i (Security)
Reverse Data Grant (RDG) Support
WLAN on/off switch
WPS Support
MANAGEMENT
TFTP client and server
DHCP client and server
FTP server and client
Universal Plug and Play (UPnP) support
Web-based Graphical User Interface (GUI) enabling end-user device configuration via HTTP
Update of boot image or configuration data via TFTP / FTP
Syslog
Built-in Diagnostic Tools
SNMP MIB support
ETHERNET INTERFACE
IEEE 802.3
10 /100 Mbps
DIMENSIONS
139mm x 116mm x 30mm
Weight: 245g
Specifications are subject to change without notice
