TDD LTE WiFi Router

Fast just got faster with the introduction of an TDD LTE WiFi Router that delivers connection speeds of up to 100Mbps downlink, and 50Mbps uplink, on TDD LTE networks worldwide. Match this with 300Mbps WiFi speeds to create a high-speed wireless network for up to 16 wireless devices simultaneously.
4gt101w
4Gt101w

LTE. The speed revolution.

Connect to the new wireless stratosphere with access to advanced LTE networks worldwide.  The TDD LTE WiFi Router levels the playing field so you can generate speeds that rival the fixed line wherever LTE coverage exists; so you no longer need access to ADSL, cable or fibre for a super-fast and reliable Internet connection.

TDD LTE technology. A leap ahead.

Enjoy the best that LTE has to offer with instant access to global TDD LTE networks.  Instead of using separate channels for uplink and downlink transmissions, TDD LTE sends and receives data on the same channel according to real-time demand to give you the best possible result.
4gt101w
4gt101w

Max WiFi.

Save a bundle by sharing your WiFi connection with 16 people or devices on a single data plan, and look forward to a fast and reliable connection at all times  with WiFi speeds of up to 300Mbps and an extra boost from the WiFi antennas. Simultaneously connect your laptop, smart phone, tablet, gaming console and more without compromising the quality of your online experience.

Technical Specifications


LTE

  • LTE TDD Cat 3, Release 8 (Downlink 100Mbps / Uplink 50Mbps)
  • Bands:
    • Band 38 (2600)
    • Band 40 (2300)
    • Band 41 (2500)
    or
    • Band 42 (3400-3600)
    • Band 43 (3600-3800)
    or
    • Band 38 (2600)
    • Band 40 (2300)
    • Band 41 (2500)
    with 3G WCDMA fallback to band 1 (2100MHz)

  • Up to 100 Mbps downlink
  • Up to 50 Mbps uplink



WWAN INTERFACE

  • 4G x 1



LAN INTERFACE

  • 10/100 Ethernet x 2

WLAN

  • MAC Address Filtering, WEP, WPA, IEEE 802.1X
Standard
  • IEEE802.11n, backward compatible with 802.11b/g
Encryption
  • WEP, WPA, WPA2
Channels
  • 11 Channels (US, Canada)
  • 13 Channels (Europe, Australia)
  • 14 Channels (Japan)
WLAN Data Rate
  • Up to 300Mbps
  •

WAN CONNECTION

PPP/IP
  • Yes



ANTENNA

  • 2 x fixed external antennas



MANAGEMENT

  • SNMP, SNTP, Web-based management, Configuration backup and restoration
  • Firmware upgrade via HTTP

ROUTING FUNCTIONS

  • Static route, NAT/PAT, DMZ, DHCP Client/Server/Relay, DNS Proxy, DDNS



SECURITY FUNCTIONS

  • Stateful Packet Inspection, Packet filtering, Denial Of Service protection, Management
Authentication protocols
  • PAP, CHAP
VPN
  • PPTP/L2TP/IPSec pass-through



LEDS

  • Power, LAN2, LAN 1, Service type



POWER

  • External power adapter
  • 100-240VAC  to  12VDC/1.5A



ENVIRONMENTAL CONDITIONS

Operating temperature
  • 0 ~ 50 degrees Celsius
Relative humidity
  • 5 ~ 90% (non-condensing)

Specifications are subject to change without notice
