HSPA+ WiFi Router (International only)

The HSPA+ WiFi Router brings high-speed Internet connectivity to homes and businesses with AWS band access. The flexible fixed wireless gateway connects to a 21Mbps 3G UMTS network  using a powerful antenna system and includes a wireless LAN access point to transmit a powerful WiFi signal to up to 10 wireless devices simultaneously.

For the best of both worlds you can connect wired devices via the Ethernet LAN ports; or use the Ethernet WAN port for a fixed ADSL2+, cable or fibre connection.

3G39W
3G39W

Supporting Advanced Wireless Services (AWS)

A bundle of practical features have been packed into this powerful wireless router to give you a high-speed Internet connection that enhances the rural and indoor coverage benefits of the AWS spectrum while maximising the spectrum's voice and data advantages using VoIP. The HSPA+ Router is compatible with all carriers that operate on the AWS frequency.

HSPA+ versatility.

Create a reliable HSPA+ connection wherever network coverage exists and enjoy download speeds of up to 21Mbps without the need for wires or cabling. Achieve fast and reliable HSPA+ network access from temporary locations with the protection of VPN pass-through for a secure connection over the public cellular network.
3G39W
3G39W

WiFi velocity

It’s all about creating a personal WiFi zone that lets you connect your laptops, desktop computers, tablets, gaming consoles and smart phones on a single broadband account to save you time and effort.  With super-fast wireless speeds of up to 300Mbps and MIMO antenna technology, connecting 10 devices at a time will not compromise performance.

Ideal Ethernet.

Offering the ultimate in flexibility, the HSPA+ WiFi Router includes 2 Ethernet ports for connecting wired devices; and one of the Ethernet ports can double as an Ethernet WAN port for an alternate fixed line (ADSL2+, cable or fibre) connection to the Internet.
3G39W

Technical Specifications

HSPA+

  • 850/AWS/1900/2100 MHz (HSPA+/HSUPA/HSDPA/WCDMA)
  • 850/900/1800/1900 MHz (EDGE/GPRS/GSM)
  • Up to 21 Mbps downlink (HSDPA Cat 14)
  • Up to 5.76 Mbps uplink (HSUPA Cat 6)

WWAN INTERFACE

  • 3G x 1

LAN INTERFACE

  • 10/100 Ethernet x 2

WLAN

Standard
  • IEEE802.11n, backward compatible with 802.11b/g
Encryption
  • WEP, WPA, WPA2
WLAN Data Rate
  • Up to 300Mbps

ANTENNA SYSTEM

  • 1 x External cellular main - removable multi-band 2dBi gain terminal mount omni antenna
  • 1 x Internal cellular diversity antenna
  • 2 x Internal 2.4GHz antennas for 802.11n WiFi

WAN CONNECTION

PPP/IP
  • Yes

MANAGEMENT

  • Web based user interface (HTTP), Firmware upgrade via LAN, System Monitoring, Diagnostic Log Viewer

ROUTING FUNCTIONS

  • WWAN (3G), PPPoE, DHCP Server/Client, Static Route, Dynamic DNS, NAT - Port Forwarding, DMZ, DNS Masquerading, RIP, PPP with PAP/CHAP, NTP

SECURITY FUNCTIONS

  • Stateful Packet Inspection, Packet filtering, Denial Of Service protection, Management
Authentication protocols
  • PAP, CHAP
VPN
  • Pass-through PPTP, IPSec, SSL

LED

  • Power, 3G, WiFi, Internet/WAN, LAN

POWER

  • External power adapter
  • DC in port: 12VDC

ENVIRONMENTAL CONDITIONS

Operating temperature
  • 0 ~ 50 degrees Celsius
Relative humidity
  • 5 ~ 90% (non-condensing)

DIMENSIONS AND WEIGHT

  • 133 mm (L) x 137 mm (H) x 34 mm (W)
  • 250 grams

REGULATORY COMPLIANCE

  • PTCRB
  • FCC
  • IC
  • RoHS

PACKAGE INCLUDES

  • 3G39W Gateway
  • 1 x 1.5M Ethernet cable
  • 1 x external antenna
  • DC power adapter
  • Quick start guide
  •
Specifications are subject to change without notice
