Dual ADSL2+ / 3G Wireless N Gateway

Designed to deliver steadfast broadband Internet access using flexible ADSL2+ or 3G connection options, the Dual ADSL2+ / 3G Wireless N Gateway features automatic failover to give Internet critical homes and businesses a connection that never fails. This simple setup device lets you create and share a high-speed 300Mbps wireless network between multiple users, and connects up to 4 wired devices using the Ethernet ports. Everyone on the network can access a printer or storage device via the USB port while benefiting from maximum network protection with a raft of security features including an advanced firewall, VPN pass-through functionality and encrypted Point-to-Point communications from connected computers.
3G29WN2 - Dual ADSL2+ / 3G Wireless N Gateway

3G29WN2 - Dual ADSL2 / 3G Wireless N Gateway

Flexible ADSL and 3G connectivity.

Connect to high-speed broadband Internet using your choice of a high-speed ADSL2+ (24Mbps) or 3G (21Mbps) connection and achieve a constant 'always on' connection with automatic failover to 3G should your ADSL connection fail. Ideal for homes and businesses that can't afford to lose broadband access, the Dual ADSL2+ / 3G Wireless N Gateway will keep you connected when the lines are down.

Robust wireless.

Laptops, tablet computers, gaming consoles, smart phones and other wireless devices can share a powerful wireless network connection with Wireless N speeds reaching 300Mbps. The economical Dual ADSL2+ / 3G Wireless N Gateway connects multiple devices on a single broadband account to reduce costs while using the latest standards of wireless security to protect your network.
3G29WN2 - Dual ADSL2 / 3G Wireless N Gateway
3G29WN2 - Dual ADSL2 / 3G Wireless N Gateway

Print and file sharing capacity.

Connect a printer or external hard drive to the 2.0 USB port to easily and efficiently share printing and file storage capabilities with everyone connected to the Dual ADSL2+ / 3G Wireless N Gateway.

Powerful wired connectivity.

The versatile Dual ADSL2+ / 3G Wireless N Gateway supplements your wireless network with up to 4 wired connections to the Ethernet ports. Connect PCs, HD TVs, Blu-ray players and other heavy-duty wired devices and achieve optimal HD streaming, multimedia and online gaming.
3G29WN2 - Dual ADSL2 / 3G Wireless N Gateway

Technical Specifications

WAN INTERFACE

  • 3G
  • ADSL2+

ADSL

  • G.992.5 (ADSL2+) (Annex M)
  • G.992.3 (ADSL2)
  • G.992.1 (Annex A)
  • G.992.2
  • ANSI T.413 Issue 2
  • ATM QoS (UBR, CBR, VBR)
  • Multiple PVCs (up to 8 supported)
  • F4/F5 OAM Loop-backs / Send & Receive
  • AAL ATM Attributes - AAL5
  • ATM UNI support: UNI3.1/4.0

ADSL ENCAPSULATION SUPPORT

  • PPPoE (RFC2516)
  • RFC 2684 (RFC 1483) Bridge
  • PPPoA (RFC2364)
  • RFC 2684 (RFC 1483) Route
  • Classical IP over ATM (RFC1577)

LAN INTERFACE

  • Ethernet x 4

WLAN

  • MAC Address Filtering, WEP, WPA, IEEE 802.1X
  • 10, 25, 50, 100mW @ 22MHz channel bandwidth. Output power level can be selected according to the environment
STANDARD
  • IEEE802.11n, backward compatible with 802.11g/b
ENCRYPTION
  • WEP, WPA, WPA2, 802.1x, WPA-PSK/WPA2-PSK
CHANNELS
  • 11 Channels (US, Canada)
  • 13 Channels (Europe, Australia)
WLAN DATA RATE
  • Up to 300Mbps

3G WAN INTERFACE

PPP
  • Yes
STANDARD
  • Comply with the 3GPP release 5
BAND
  • Support Quad-band GSM/GRPS (850 / 900 / 1800 / 1900 MHz)
  • Support Quad-band UTMS/HSDPA/HSUPA (850 / 900 / 1900 / 2100 MHz)
DATA RATE
  • HSUPA (up to 5.76 Mbps uplink)
  • HSDPA and UMTS (up to 21Mbps downlink)
  • EDGE / GPRS / GSM (up to 247 Kbps)
ANTENNA TYPE
  • Removable 3G antenna

MANAGEMENT

  • SNMP, SNTP, Telnet, Web-based management, Configuration backup and restoration
  • Firmware upgrade via HTTP, TFTP client and server, or FTP server

ROUTING FUNCTIONS

  • Static route, NAT/PAT, DMZ, DHCP Client/Server/Relay, DNS Proxy, DDNS

SECURITY FUNCTIONS

  • Stateful Packet Inspection, Packet filtering, Denial Of Service protection, Management
AUTHENTICATION PROTOCOLS
  • PAP, CHAP
VPN
  • PPTP/L2TP/IpSec pass-through

LED

  • Power, ADSL2+, Internet, LAN 1-4, WLAN, 3G, 2G, Signal Strength for Low, USB, Mid and High LEDs

POWER

  • External power adapter
  • 100-240 VAC to 12VDC /1.5A

ENVIRONMENTAL CONDITIONS

OPERATING TEMPERATURE
  • 0 ~ 50 degrees Celsius
RELATIVE HUMIDITY
  • 5 ~ 90% (non-condensing)

DIMENSIONS

  • 215 mm (W) x 37 mm (H) x 145 mm (D)
Specifications are subject to change without notice
