Telstra Turbo™ Gateway

Boost the productivity of your mobile workforce with a Gateway that combines Telstra's Next G™ service with fast and secure WiFi and Ethernet connectivity. Deliver the speed and coverage benefits of Telstra's Next G™ network to multiple wireless and wired devices without fixed line restrictions, and make cost-effective voice calls over the Next G™ network. The feature packed device supports all of your online needs with: 2 Ethernet ports for wired connectivity, 54Mbps wireless networking, a 2.0 USB port, voice capabilities and 2 removable antennas.
3G10WVT
3G10WVT

Instant Next G™ access.

Simply insert an active Telstra Next G™ SIM card into the slot on the rear of the Gateway to achieve a secure connection to Australia's leading mobile broadband network. This office-in-a-box Gateway delivers HSPA speeds reaching 7.2Mbps to support all of your online communication needs.

Standard phone, extraordinary potential.

Ideal for mobile workers and temporary office setups, the Telstra Turbo™ Gateway lets you make regular phone calls over the Next G™ network by simply connecting a standard PSTN telephone to the RJ-11 voice port.
3G10WVT
3G10WVT

Cost-effective wireless.

Reduce connection costs and streamline your accounts with a versatile wireless connection with the capacity to connect up to 20 wireless devices such as notebooks, tablet computers and smart phones on a single broadband account. The Telstra Turbo™ Gateway gives multiple users simultaneous access to a convenient WiFi network with speeds peaking at 54Mbps.

Wired connectivity.

Connect 2 wired devices of your choice to the 10/100 LAN ports for a dependable high-speed connection that supports bandwidth-intensive activities including multimedia applications and HD streaming.
3G10WVT

Technical Specifications

WAN INTERFACE

  • HSPA x 1

LAN INTERFACE

  • Ethernet x 2

VOICE

  • 1 x RJ11 Voice port (circuit-switched)

USB 2.0

  • Print Server or File Server (auto-sensing)

WLAN

  • MAC Address Filtering, WEP, WPA, IEEE 802.1X
  • 10, 25, 50, 100mW @ 22MHz channel bandwidth Output power level can be selected according to the environment
Standard
  • IEEE 802.11g, backward compatible with 802.11b
Encryption
  • 64, 128-bit Wired Equivalent Privacy (WEP, WPA2) Data Encryption
Channels
  • 11 Channels (US, Canada)
  • 13 Channels (Europe, Australia)
  • 14 Channels (Japan)
WLAN Data Rate
  • Up to 54Mbps

WAN CONNECTION PPP

  • IP compression
  • Data compression
Standard
  • Comply with the 3GPP release 5 UMTS specification
Band
  • Support Quad-band GSM/GRPS(850 / 900 / 1800 / 1900 MHz)
  • Support tri-band UMTS/HSDPA/HSUPA(850 / 1900 /2100 MHz)
Data Rate
  • HSUPA (up to 5.8Mbps uplink)
  • HSDPA and UMTS (up to 7.2 Mbps downlink)
  • EDGE / GPRS / GSM (up to 247 Kbps)
Antenna Type
  • Removable 3G antenna
  • Removable 802.11g antenna

MANAGEMENT

  • SNMP, SNTP, Telnet, Web-based management, Configuration backup and restoration
  • Firmware upgrade via HTTP, TFTP client and server, or FTP server

ROUTING FUNCTIONS

  • Static/Dynamic route
  • Static route, DMZ, DNS Proxy, DDNS
  • NAT/PAT, NAT enable/disable to support Telstra IP WAN service
  • DHCP Client/ Server/Relay
  • Half-bridging mode

SECURITY FUNCTIONS

  • Stateful Packet Inspection, Packet filtering, Denial Of Service protection, Management

SIM PIN FUNCTIONS

  • Unlock PIN code, Change PIN code
Authentication protocols
  • PAP, CHAP

VPN

  • PPTP/L2TP/IP Sec pass-through

LEDS

  • Power, Phone, Fax, USB, LAN2, LAN 1, Wi-Fi, Internet, 3G, 2G, Signal Strength - Low, Med, High

POWER

  • External power adapter
  • 100-240Vac  to  12Vdc /1.5A

ENVIRONMENTAL CONDITIONS

Operating temperature
  • 0 ~ 50 degrees Celsius
Relative humidity
  • 5 ~ 90% (non-condensing)

DIMENSIONS

  • 205 mm (W) x 47 mm (H) x 145 mm (D)
Specifications are subject to change without notice
